Mini color mark sensor KTM-WN11181P
KTM-WN11181P color mark sensor is widely use in the Printing machine , bag making machine , slitting machine and lamination machine
FEATURES
· Sensing distance: 10 mm
· Light spot size: 1.2 mm x 4.2 mm
· Switching frequency: 10 kHz
· Type of light: RGB
· Connection type: Male connector M12, 5-pin
· Adjustment: Static 2-point teach-in
· Communication interface: -
MECHANICS/ELECTRONICS
|
Supply voltage |
10 V DC ... 30 V DC 1) |
|
Ripple |
≤ 5 Vpp 2) |
|
Power consumption |
<800 mA 3) |
|
Switching frequency |
10 kHz 4) |
|
Response time |
50 µs |
|
Output type |
NPN |
|
Switching output (voltage) |
NPN: HIGH = approx. VS / LOW ≤ 2 V |
|
Output current Imax. |
100 mA |
|
Retention time (ET) |
25 ms, non-volatile memory |
|
Connection type |
Male connector M12, 4-pin |
|
Protection class |
II 5) |
|
Circuit protection |
UV connections, reverse polarity protected Output Q short-circuit protected Interference pulse suppression |
|
Enclosure rating |
IP 67 |
|
Weight |
400 g |
|
Housing material |
Zinc diecast |
1) Limit values when operated in short-circuit protected network: max. 8 A.
2) May not exceed or fall below Uv tolerances.
3) Without load.
4) With light/dark ratio 1:1.
5) Signal transit time with resistive load.
6) Short-circuit protected.
7) Reference voltage DC 50 V.
AMBIENT DATA
|
Ambient operating temperature |
–10 °C ... +55 °C |
|
Ambient storage temperature |
–25 °C ... +75 °C |
|
Shock load |
According to IEC 60068 |
